Lumanor LED Lamps - Product Categories - GU10 LED Spotlights - 6W COB

Lumanor LED Lamps - Product Categories - GU10 LED Spotlights - 5W COB

Cold-Forged Aluminium Alloy heat sink surrounded by ultra-high conductivity thermo-plastic for excellent thermal management

Ultra-high transmittance (90%) PMMA lens provides even light distribution & eliminates glare

Lumanor COB LED chip offers unrivalled brightness & light quality - up to 470lm at 6000K with Ra 85

Lumanor LED Driver Technology

provides the ultimate in dimming

performance

Lumanor 5W COB GU10

Ultra-high Conductivity Thermoplastic surround

High-Purity Aluminium Alloy heat sink

Electrically Insulating Pressure Ring

4500V Flash Test

The outer layer of the Lumanor GenIII 5W COB GU10 together with
the pressure ring make use of the latest in ultra-high conductivity
thermoplastics to full protection during the 4500V Flash Test

Together with exceeding the 4500V Flash Test requirements the
Lumanor GenIII 5W COB GU10 range provides flame resistance to
UL94V0

Flame Resistance

Like its predecessors, the Lumanor GenIII 5W GU10
range offers excellent thermal management control and
heat dissipation. By utilising a High-Purity Al-Alloy core
coated with ultra-high conductivity thermoplastic, the
GenIII range is able to offer the same outstanding
lumen performance whilst simultaneously reducing
weight and production time meaning reduced costs and
less environmental impact

Flame Resistance

Lumanor GU10 5W COB

Configuration: 1 x 5W LED COB chip

Rating: 5W

Available in Warm White (2700K), Natural White (4500K),

& Cool White (6000K)

3 years warranty

Up to 35,000 hours lifetime

Dimensions: 50mm x 58mm

Beam angle 38 degrees



Dimmable



Lumenous Output:



440lm at 2700K

450lm at 4500K

470lm at 6000K

Equivalent to 50W Halogen



COBGU105WW

COBGU105WWD

COBGU105NW

COBGU105NWD

COBGU105CWD

Lumanor™ COB GU10 5W Warm White 2700K, 220-240V AC 50Hz

Lumanor™ COB GU10 5W Warm White 2700K, 220-240V AC 50Hz Dimmable

Lumanor™ COB GU10 5W Natural White 4500K, 220-240V AC 50Hz

Lumanor™ COB GU10 5W Natural White 4500K, 220-240V AC 50Hz Dimmable

Lumanor™ COB GU10 5W Cool White 6000K, 220-240V AC 50Hz Dimmable
